- Profesionálny syntetizátor, aranžér, pracovná stanica
- 76 klávesová FSX
keyboard
- Motion Control Synthesis Engine spája dva zvukové enginy
- 128 stereo hlasová polyfónia
- hmotnosť: 17 kg
Size/Weight
| Dimensions | Width | 1,037 mm (40-13/16") |
|---|
| Height | 131 mm (5-3/16") |
|---|
| Depth | 396 mm (15-9/16") |
|---|
| Weight | Weight | 15 kg (33 lbs., 1 oz.) |
|---|
Control Interface
| Keyboard | Number of Keys | 61 |
|---|
| Type | FSX Keyboard |
|---|
| Initial Touch | Yes |
|---|
| Aftertouch | Yes |
|---|
Tone generator
| Tone Generator | Motion Control Synthesis Engine AMW2: 8 Elements FM-X: 8 Operators, 88 Algorithms |
|---|
| Maximum Polyphony | AWM2: 128 (max.; stereo/mono waveforms) FM-X: 128 (max.) |
|---|
| Multi Timbral Capacity | 16 Parts (internal), Audio Input Parts (A/D*, USB*) *stereo Part |
|---|
| Wave | Preset: 5.67 GB (when converted to 16 bit linear format), User: 1.75 GB |
|---|
| Performance | Approx. 1,900 |
|---|
| Filter | 18 types |
|---|
| Effects | Reverb
x 12 types, Variation x 76 types, Insertion (A, B) x 76 types*, Master
Effect x 15 types *A/D part insertion x 71 types (Preset settings for
parameters of each effect type are provided as templates) Master EQ (5
bands), 1st part EQ (3 bands), 2nd part EQ (2 bands) |
|---|
Other
| Controllers | Master
Volume, AD Input Gain knob, Pitch Bend wheel, Modulation wheel, Ribbon
Controller, Control Sliders x 8, Knobs x 8, Super Knob, Data dial |
|---|
| Display | 7" TFT Color Wide VGA LCD touch screen |
|---|
| Connectors | [USB
TO DEVICE], [USB TO HOST], MIDI [IN]/[OUT]/[THRU], FOOT CONTROLLER
[1]/[2], FOOT SWITCH [ASSIGNABLE]/[SUSTAIN], OUTPUT (BALANCED)
[L/MONO]/[R] (6.3 mm, Balanced TRS jacks), ASSIGNABLE OUTPUT (BALANCED)
[L]/[R] (6.3 mm, Balanced TRS jacks), [PHONES] (6.3 mm, standard stereo
phone jack), A/D INPUT [L/MONO]/[R] (6.3 mm, standard phone jacks) |
|---|
| Power Consumption | 27 W |
|---|
| Accessories | AC Power cord, Owner’s Manual, Cubase AI Download Information |
|---|
| Live Sets | Preset: 128 and more, User: 2,048 |
|---|
